Description
Weight: 1150gsm (33.92oz/sq.yd)
Base Fabric: Fiberglass EC3/4
Coating: PTFE
Thickness: 0.65±0.05mm
Max Width: 300cm/118″ & 380cm/150″
Tensile Strength (Warp/Weft): 6500/6000 N/5cm
Tear Strength (Warp/Weft): 550/500 N
Adhesion Strength: 90 N/5cm
Light Transmittance: 12%
Light Reflectivity: 80%
Welding Retention: 100%
Flame Resistance: FR reach GB8624/EN13501
Features:
Dip coating with imported Japanese PTFE emulsion
Light transmittance ≥ 12%
25+ years of outdoor service life
Woven with EC3/4 β glass yarn
Rapid photo-bleaching
Flame retardant performance meets GB 8624 Class A / EN 13501-1 standards
UV protection rate ≥ 99%
Infrared reflectivity ≥ 95%
Self-cleaning properties maintained throughout the entire service life
Long-term anti-mildew and anti-corrosion properties
Resistant to strong acids and alkalis
UNISIGN is a professional manufacturer & supplier of high-performance PTFE coated fiberglass fabrics based in China. Our 1150gsm PTFE fabric meets international standards and is widely used in architectural and industrial applications worldwide.
